Same model may have multiple batches, images only for reference.

CTLQ1206NF-5R6J

Get a Quote

Part No	CTLQ1206NF-5R6J
Manufacturer	Central Technologies
Catalog	Fixed Inductors
Description	5.6UH 115MA SMD WW INDUCTOR
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Inductors, Coils, Chokes - Fixed Inductors
Mfr	Central Technologies
Series	CTLQ1206NF
Package	Tape & Reel
Product Status	Active
Type	Wirewound
Inductance	5.6 µH
Tolerance	±5%
Current Rating (Amps)	115 mA
Shielding	Unshielded
DC Resistance (DCR)	2.34Ohm Max
Q @ Freq	35 @ 8MHz
Frequency - Self Resonant	28MHz
Temperature Range - Operating	-25°C ~ 85°C
Inductance Frequency - Test	1 MHz
Mounting Type	Surface Mount
Package / Case	1206 (3216 Metric)
Supplier Device Package	1206
Size / Dimension	0.126" L x 0.063" W (3.20mm x 1.60mm)
Height - Seated (Max)	0.079" (2.00mm)
Standard Package	1 pcs
MSL Level	Vendor Undefined
REACH Status	REACH info available upon request
Win Source Part Number	580961-CTLQ1206NF-5R6J
Ultra Librarian 3D Model	Ultra Librarian CTLQ1206NF-5R6J CAD Model

Alternative Products

Description

The CTLQ1206NF-5R6J is a fixed inductor from Central Technologies.

Type: Wirewound
Inductance: 5.6 µH
Tolerance: ±5%
Size: 0.126" L x 0.063" W (3.20mm x 1.60mm)
Temperature Range: -25°C to 85°C
Package: Surface Mount 1206
Current Rating: 115 mA
Status: Active
