Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories RF/IF and RFID
Manufacturer CEL
Packaging Reel - TR
Status Obsolete(EOL)
Frequency 2.2GHz to 2.6GHz
Gain 11dB to 16.5dB
Noise Figure 4.5dB to 6dB
RF Type Cellular, DBS, PCS
Supply Voltage - Operating 4.5 V to 5.5 V
Operating Supply Current 9mA to 15mA
Case / Package SOT-363
Win Source Part Number 401189-UPC2712T
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian UPC2712T CAD Model

Description

The CEL 401189-UPC2712T is an RF/IF and RFID product that operates @ a frequency range of 2.2GHz to 2.6GHz.

  • Gain: 11dB to 16.5dB
  • Noise Figure: 4.5dB to 6dB
  • Product Status: obsolete (EOL)
  • Supply and Demand Status: balanced
  • Case/Package: SOT-363
  • Supply Voltage Operating Range: 4.5 V to 5.5 V
  • Operating Supply Current: 9mA to 15mA
  • Alternative Parts (cross-reference): HMC3653LP3BE, UPC2712T-A, and UPC2712T-E3
