PS9117-F3-A Real Image PS9117-F3-A label picture PS9117-F3-A real image
Same model may have multiple batches, images only for reference.
PS9117-F3-A Real Image PS9117-F3-A label picture PS9117-F3-A real image
PS9117-F3-A Real Image PS9117-F3-A label picture PS9117-F3-A real image
Same model may have multiple batches, images only for reference.

PS9117-F3-A

Part No PS9117-F3-A
Manufacturer CEL
Catalog Optoisolators - Logic Output
Description OPTOISO 3.75KV OPN COLLECTOR 5SO
Datasheet
PS9117-F3-A Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer CEL
Packaging Reel - TR
Status Obsolete(EOL)
Number of Channels 1
Inputs - Side 1/Side 2 1/0
Isolation Voltage 3750Vrms
Common Mode Transient Immunity (Min) 15kV/μs
Input Type DC
Output Type Open Collector
Channel Output Current 25mA
Data Rate 10Mbps
Propagation Delay tpLH / tpHL (Max) 75ns, 75ns
Rise and Fall Time 20ns, 5ns
Forward Voltage 1.65V
Continuous forward current- Max 30mA
Supply Voltage - Operating 4.5 V to 5.5 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 5-SO
Win Source Part Number 281501-PS9117-F3-A
Popularity Medium
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian PS9117-F3-A CAD Model

Description

The CEL 281501-PS9117-F3-A optoisolator is used to isolate two circuits from each other.

  • Product: CEL 281501-PS9117-F3-A
  • Data Rate: 10Mbps
  • Forward Voltage: 1.65V
  • Channel Count: single
  • Temperature Range: -40°C to 85°C
  • Package: 5-SO
  • Common Mode Transient Immunity: 15kV/μs
  • Isolation Voltage: 3750Vrms
  • Channel Output Current: 25mA
  • Supply and Demand Status: sufficient
