PS2505L-4 NEC PS2505L-4 Real Image
Same model may have multiple batches, images only for reference.
PS2505L-4 NEC PS2505L-4 Real Image
PS2505L-4 NEC PS2505L-4 Real Image
Same model may have multiple batches, images only for reference.

PS2505L-4

Part No PS2505L-4
Manufacturer CEL
Catalog Optoisolators - Transistor, Photovoltaic Output
Description OPTOISOLTR 5KV 4CH TRANS 16-SMD / Optoisolator Transistor Output 5000Vrms 4 Channel 16-SMD
Datasheet
PS2505L-4 Datasheet
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Category Isolators - Optoisolators - Transistor, Photovoltaic Output Optoisolators
Mfr CEL
Series NEPOC
Package Tube
Product Status Obsolete
Number of Channels 4
Voltage - Isolation 5000Vrms
Current Transfer Ratio (Min) 80% @ 5mA
Current Transfer Ratio (Max) 600% @ 5mA
Rise / Fall Time (Typ) 3µs, 5µs
Input Type AC, DC
Output Type Transistor
Voltage - Output (Max) 80V
Current - Output / Channel 50mA
Voltage - Forward (Vf) (Typ) 1.17V
Current - DC Forward (If) (Max) 80 mA
Vce Saturation (Max) 300mV
Temperature Range - Operating -55°C ~ 100°C
Mounting Type Surface Mount
Package / Case 16-SMD, Gull Wing
Supplier Device Package 16-SMD
Standard Package 20 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Affected
ECCN EAR99
HTSUS 8541.49.8000
Win Source Part Number 656795-PS2505L-4
Ultra Librarian 3D Model Ultra Librarian PS2505L-4 CAD Model

Description

The PS2505L-4 is an optoisolator with a transistor output, designed for applications requiring high isolation voltage.

  • Current Transfer Ratio: 80% @ 5mA
  • Voltage Isolation: 5000Vrms
  • Maximum Forward Current: 80mA
  • Package: Surface mount
  • Operating Temperature: -55°C to 100°C
  • Series: NEPOC
  • Status: Obsolete
