PS2502-4-A Real Image PS2502-4-A real image4950 PS2502-4-A real image4951 PS2502-4-A Real Image
Same model may have multiple batches, images only for reference.
PS2502-4-A Real Image PS2502-4-A real image4950 PS2502-4-A real image4951 PS2502-4-A Real Image
PS2502-4-A Real Image PS2502-4-A real image4950 PS2502-4-A real image4951 PS2502-4-A Real Image
Same model may have multiple batches, images only for reference.

PS2502-4-A

Part No PS2502-4-A
Manufacturer CEL
Catalog Optoisolators - Transistor, Photovoltaic Output
Description OPTOISO 5KV 4CH DARLINGTON 16DIP
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer CEL
Packaging Tube/Rail
Status Active
Number of Channels 4
Isolation Voltage 5000Vrms
Minimum DC Current Transfer Ratio 200% @ 1mA
Rise and Fall Time 100μs, 100μs
Input Type DC
Output Type Darlington
Maximum Output Voltage 40V
Channel Output Current 160mA
Forward Voltage 1.17V
Continuous forward current- Max 80mA
Vce Saturation (Max) 1V
Temperature Range - Operating -55°C to 100°C
Mounting Through Hole
Case / Package 16-DIP
Win Source Part Number 026866-PS2502-4-A
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian PS2502-4-A CAD Model

Description

The CEL PS2502-4-A is a through-hole mounted, four channel Darlington output type optocoupler.

  • Isolation Voltage: 5000Vrms
  • Forward Voltage: 1.17V
  • Minimum DC Current Transfer Ratio: 200% @ 1mA
  • Maximum Output Voltage: 40V
  • Channel Output Current: 160mA
  • Continuous Forward Current: 80mA
  • Suitable for: use in isolator applications
  • Package: 16-DIP package
