RTAP31S12WFLSS C&K Components
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Category Switches - Rotary Switches
Mfr C&K
Series RTA
Package Bag
Product Status Active
Number of Positions 12
Index Stops Fixed
Number of Decks 1
Number of Poles per Deck 1
Circuit per Deck SP12T
Contact Timing Non-Shorting (BBM)
Current Rating (Amps) 150mA (AC/DC)
Voltage Rating - AC 60 V
Voltage Rating - DC 60 V
Actuator Type Screwdriver Slot
Actuator Length Flush
Angle of Throw 30°
Contact Material Brass
Contact Finish Silver
Mounting Type Through Hole
Termination Style PC Pin
Features -
Depth Behind Panel 12.60mm
Panel Cutout Dimensions -
Base Product Number RTAP31
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8536.50.9020
Win Source Part Number 1375948-RTAP31S12WFLSS
Ultra Librarian 3D Model Ultra Librarian RTAP31S12WFLSS CAD Model

Description

The RTAP31S12WFLSS is a through-hole rotary switch from the RTA series manufactured by C&K.

  • Series: RTA
  • Positions: 12
  • Current Rating: 150mA (AC/DC)
  • Actuator Style: Screwdriver Slot
  • Termination Style: PC Pin
  • Voltage Rating: 60V AC/DC
  • Actuator Length: Flush
  • Contact Timing: Non-Shorting
  • Electrical Life: 40,000 Cycles
  • Contact Finish: Silver
  • Contact Material: Brass
