Same model may have multiple batches, images only for reference.

MGA-72543-TR1G

Name: MGA-72543-TR1G
Brand: Broadcom Limited
SKU: 228487
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	MGA-72543-TR1G
Manufacturer	Broadcom Limited
Catalog	RF Amplifiers
Description	RF Amp Single LNA 6GHz 4.2V 4-Pin(3+Tab) SOT-343 T/R / IC AMP MMIC LNA GAAS 3V SOT-343
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	RF/IF and RFID
Manufacturer	Broadcom Limited
Packaging	Reel - TR
Status	Active
Frequency	100MHz to 6GHz
P1dB	3.2dBm (2.1mW) to 17.1dBm (51.3mW) @ 5mA to 60mA
Gain	13.6dB
Noise Figure	1.42dB
RF Type	CDMA, TDMA
Supply Voltage - Operating	2.7 V to 4.2 V
Operating Supply Current	60mA to 70mA
Test Frequency	2GHz
Case / Package	SOT-343, SC70 4-Lead
Win Source Part Number	023215-MGA-72543-TR1G
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Balance
Quantity per package	3k pcs
Family Name	MGA-72543
Introduction Date	April 01, 2004
ECCN	5A991.g
Country of Origin	Thailand, Malaysia
Estimated EOL Date	Obsolete / End of life
Ultra Librarian 3D Model	Ultra Librarian MGA-72543-TR1G CAD Model

Alternative Products

Description

The Broadcom Limited MGA-72543-TR1G is a high-gain, low-noise amplifier designed for CDMA and TDMA RF applications.

Frequency Range: 100MHz to 6GHz
Test Frequency: 2GHz
Gain: 13.6dB
Noise Figure: 1.42dB
Supply Voltage: 2.7 V to 4.2 V
Operating Supply Current: 60mA to 70mA
Component Type: Surface-mount device (SMD)
Package: SOT-343, SC70 4-Lead
Supply and Demand Status: Balanced
Package Size: 3k pcs
ECCN: 5A991.g compliant
Manufactured in: Thailand and Malaysia
