MGA-30116-BLKG Real Image MGA-30116-BLKG real image
Same model may have multiple batches, images only for reference.
MGA-30116-BLKG Real Image MGA-30116-BLKG real image
MGA-30116-BLKG Real Image MGA-30116-BLKG real image
Same model may have multiple batches, images only for reference.

MGA-30116-BLKG

Part No MGA-30116-BLKG
Manufacturer Broadcom Limited
Catalog RF Amplifiers
Description 150MHz – 1GHz 1/2 Watt High Linearity Amplifier Standard QFN 3X3 package | IC RF AMP CDMA 400MHZ-1GHZ 16QFN
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories RF/IF and RFID
Manufacturer Broadcom Limited
Packaging Strip
Status Obsolete
Frequency 400MHz ~ 1GHz
P1dB 27.7dBm
Gain 17dB
Noise Figure 2dB
RF Type CDMA, GSM
Supply Voltage (V) 5V
Supply Current 400mA
Test Frequency 900MHz
Manufacturer Package 16-VFQFN Exposed Pad
Supplier Device Package 16-QFN (3x3)
Manufacturer Pack Quantity 100
MSL Level 1 (Unlimited)
Win Source Part Number 1221829-MGA-30116-BLKG
Manufacturer Homepage www.avagotech.com
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian MGA-30116-BLKG CAD Model

Description

The MGA-30116-BLKG is an electronic component manufactured by Broadcom Limited.

  • Supply and Demand Status: limited
  • Product Type: RF amplifier
  • Test Frequency: 900MHz
  • Frequency Range: 400MHz to 1GHz
  • Gain: 17dB
  • Supply Current: 400mA
  • Noise Figure: 2dB
  • P1dB: 27.7dBm
  • RF Types: CDMA and GSM
  • Supplier Device Package: 16-QFN (3x3)
  • Status: obsolete
  • Manufacturer Homepage: www.avagotech.com
  • Manufacturer Package: 16-VFQFN Exposed Pad
  • Pieces per Pack: 100
  • MSL Level: 1 (unlimited)
  • Supply Voltage: 5V
