HEDL-5561#J06 Real Image
Same model may have multiple batches, images only for reference.

HEDL-5561#J06

Part No HEDL-5561#J06
Manufacturer Broadcom Limited
Catalog Encoders
Description ROTARY ENCODER OPTICAL 1024PPR
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Sensors, Transducers - Encoders - Industrial
Mfr Broadcom Limited
Series HEDL
Package Bulk
Product Status Active
Encoder Type Optical
Output Type Quadrature (Incremental)
Pulses per Revolution 1024
Voltage - Supply 5V
Actuator Type 1/4" Open Center
Detent No
Built in Switch No
Mounting Type Chassis Mount, Motors
Orientation Vertical
Termination Style Cable with Connector
Base Product Number HEDL-5561
Standard Package 20 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8543.70.4500
Win Source Part Number 920134-HEDL-5561#J06
Ultra Librarian 3D Model Ultra Librarian HEDL-5561#J06 CAD Model

Description

The Broadcom Limited 920134-HEDL-5561#J06 is an industrial encoder suitable for various applications.

  • Series: HEDL
  • Package: bulk
  • Standard Package Quantity: 20 pieces
  • Output Type: quadrature (incremental)
  • Actuator Type: 1/4" open center
  • Encoder Type: optical
  • Pulses per Revolution: 1024
  • Mounting: chassis mount and motor applications
  • MSL Level: 1 (unlimited)
  • REACH: unaffected
  • HTSUS Code: 8543.70.4500
  • Manufacturer: Broadcom Limited
