HCPL-6531 Real Image
Same model may have multiple batches, images only for reference.

HCPL-6531

Part No HCPL-6531
Manufacturer Broadcom Limited
Catalog Optoisolators - Transistor, Photovoltaic Output
Description Hermetically Sealed, Transistor Output Optocouplers for Analog and Digital Applications | OPTOISO 1.5KV TRANS W/BASE CLCC
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Broadcom Limited
Packaging Bulk
Number of Channels 2
Voltage - Isolation 1500VDC
Current Transfer Ratio (Minimum) 9% at 16mA
Turn On / Turn Off Time 400ns, 1μs
Input Type DC
Output Type Transistor with Base
Maximum Output Voltage 20V
Current - Output / Channel 8mA
Voltage - Forward (Vf) 1.55V
Current - DC Forward (If) (Maximum) 20mA
Temperature Range - Operating -55°C ~ 125°C
Mounting Style SMD
Manufacturer Package 20-CLCC
Supplier Device Package 20-LCC (8.89x8.89)
Manufacturer Pack Quantity 1
MSL Level 3 (168 Hours)
Win Source Part Number 1179134-HCPL-6531
Manufacturer Homepage www.home.agilent.com
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian HCPL-6531 CAD Model

Description

The Broadcom Limited HCPL-6531 is an optocoupler with a transistor with base output type.

  • Product Name: HCPL-6531
  • Output Type: Transistor with base
  • Input Type: DC
  • Number of Channels: 2
  • Current Output per Channel: 8mA
  • Voltage Isolation: 1500VDC
  • Current Transfer Ratio: 9% @ 16mA
  • Forward Current: 20mA
  • Supply Voltage: 1.55V
  • Maximum Output Voltage: 20V
  • Package: 20-CLCC
  • Operating Temperature: -55°C to 125°C
  • Application: Isolators
