HCPL-4502-000E Real Image HCPL-4502-000E real image4568
Same model may have multiple batches, images only for reference.
HCPL-4502-000E Real Image HCPL-4502-000E real image4568
HCPL-4502-000E Real Image HCPL-4502-000E real image4568
Same model may have multiple batches, images only for reference.

HCPL-4502-000E

Part No HCPL-4502-000E
Manufacturer Broadcom Limited
Catalog Optoisolators - Transistor, Photovoltaic Output
Description Optocoupler DC-IN 1-CH Transistor With Base DC-OUT 8-Pin PDIP Tube / OPTOISOLATOR 3.75KV TRANS 8-DIP
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Broadcom Limited
Packaging Tube/Rail
Status Active
Number of Channels 1
Isolation Voltage 3750Vrms
Minimum DC Current Transfer Ratio 19% @ 16mA
Maximum DC Current Transfer Ratio 50% @ 16mA
Switching Turn-On and Turn-Off Time 200ns, 600ns
Input Type DC
Output Type Transistor
Maximum Output Voltage 20V
Channel Output Current 8mA
Forward Voltage 1.5V
Continuous forward current- Max 25mA
Temperature Range - Operating -55°C to 100°C
Mounting Through Hole
Case / Package 8-DIP
Win Source Part Number 139155-HCPL-4502-000E
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Quantity per package 50
Family Name HCPL-4502
Introduction Date May 31, 2005
ECCN EAR99
Country of Origin Singapore, Thailand
Halogen Free Compliant
Estimated EOL Date 2026
Ultra Librarian 3D Model Ultra Librarian HCPL-4502-000E CAD Model

Description

The HCPL-4502-000E is an isolator manufactured by Broadcom Limited featuring a transistor output type and a DC input type.

  • Output Type: Transistor
  • Input Type: DC
  • Isolation Voltage: 3750Vrms
  • Temperature Range: -55°C to 100°C
  • DC Current Transfer Ratio (Minimum): 19% @ 16mA
  • DC Current Transfer Ratio (Maximum): 50% @ 16mA
  • Switching Turn-On Time: 200ns
  • Switching Turn-Off Time: 600ns
  • Maximum Output Voltage: 20V
  • Channel Output Current: 8mA
  • Continuous Forward Current-Max: 25mA
  • Mounting Type: Through-Hole
  • Package: Tube/Rail
  • Supply and Demand: Limited supply and demand
