SRF3225TAC-220Y Real Image
Same model may have multiple batches, images only for reference.

SRF3225TAC-220Y

Part No SRF3225TAC-220Y
Manufacturer Bourns Inc.
Catalog Common Mode Chokes
Description CMC,3.2X2.5X2.5MM,22UH,80V,0.25A  /  22 µH 2 Line Common Mode Choke Surface Mount 1.1 kOhms 250mA DCR 500mOhm
Datasheet
SRF3225TAC-220Y Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Filters>Common Mode Chokes
Mfr Bourns Inc.
Series SRF3225TAC
Package Tape & Reel
Number of Lines 2
Impedance @ Frequency 1.1 kOhms @ 10 MHz
Inductance @ Frequency 22 µH @ 100 kHz
Current Rating (Max) 250mA
DC Resistance (DCR) (Max) 500mOhm
Voltage Rating - DC 80V
Temperature Range - Operating -55°C ~ 150°C
Ratings AEC-Q200
Mounting SMD (SMT)
Dimension 0.126" L x 0.098" W (3.20mm x 2.50mm)
Height (Max) 0.098" (2.50mm)
Package / Case Horizontal, 4 PC Pad
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.50.8000
Other Names 118-SRF3225TAC-220YTR,118-SRF3225TAC-220YCT,118-SRF3225TAC-220YDKR
Standard Package 2,000
Win Source Part Number 1097458-SRF3225TAC-220Y
Ultra Librarian 3D Model Ultra Librarian SRF3225TAC-220Y CAD Model

Description

The Bourns Inc. SRF3225TAC-220Y is a common mode choke filter designed for use in AEC-Q200 rated applications. It has a voltage rating of 80V and a current rating of 250mA.

  • Application: AEC-Q200 Rated
  • Voltage Rating: 80V
  • Current Rating: 250mA
  • Packaging: Tape and Reel
  • Height: 0.098 inches
  • Configuration: 2-Line
  • Impedance: 1.1 kOhms @ 10 MHz
  • Inductance: 22 µH @ 100 kHz
  • Maximum DC Resistance: 500mOhm
  • REACH: Unaffected
  • ECCN: EAR99
