CHV0805-FX-2004EST

Name: CHV0805-FX-2004EST
Brand: Bourns Inc.
SKU: 1031615
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

Part No	CHV0805-FX-2004EST
Manufacturer	Bourns Inc.
Catalog	Chip Resistor - Surface Mount
Description	RESHV ST 0805 2M 1% 0.125W TCR10 / 2 MOhms ±1% 0.125W, 1/8W Chip Resistor 0805 (2012 Metric) High Voltage Thick Film
Datasheet	CHV0805-FX-2004EST Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Resistors>Chip Resistor - Surface Mount
Mfr	Bourns Inc.
Series	CHV-ST
Package	Tape & Reel
Resistance	2 MOhms
Tolerance	±1%
Power (Watts)	0.125W, 1/8W
Composition	Thick Film
Features	High Voltage
Temperature Coefficient	±100ppm/°C
Temperature Range - Operating	-55°C ~ 155°C
Package / Case	0805 (2012 Metric)
Supplier Device Package	0805
Dimension	0.079" L x 0.049" W (2.00mm x 1.25mm)
Height - Seated (Max)	0.024" (0.60mm)
Number of Terminations	2
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8533.21.0030
Other Names	118-CHV0805-FX-2004ESTDKR,118-CHV0805-FX-2004ESTTR,118-CHV0805-FX-2004ESTCT
Standard Package	5,000
Win Source Part Number	1031615-CHV0805-FX-2004EST
Ultra Librarian 3D Model	Ultra Librarian CHV0805-FX-2004EST CAD Model

Description

The Bourns Inc. CHV0805-FX-2004EST is a chip resistor that belongs to the CHV-ST series.

Feature: designed to have a high voltage capacity
Tolerance: ±1%
Packaging: tape and reel
Standard Package: 5,000
Temperature Coefficient: ±100ppm/°C
Power Rating: 0.125W, 1/8W
Material: thick film
Terminations: 2
Resistance: 2 MOhms
Operating Temperature: -55°C to 155°C
