SRU1048A-330Y

Part No SRU1048A-330Y
Manufacturer Bourns Inc.
Catalog Fixed Inductors
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes>Fixed Inductors
Mfr Bourns Inc.
Series SRU1048A
Package Tape & Reel
Type Drum Core, Wirewound
Material - Core Ferrite
Inductance 33 µH
Tolerance ±30%
Current Rating (Amps) 2.1 A
Current - Saturation (Isat) 1.7A
Shielding Shielded
DC Resistance (DCR) 84mOhm Max
Q @ Freq 24 @ 2.52MHz
Frequency - Self Resonant 10MHz
Ratings AEC-Q200
Temperature Range - Operating -40°C ~ 125°C
Inductance Frequency - Test 100 kHz
Mounting SMD (SMT)
Package / Case Nonstandard
Dimension 0.394" L x 0.394" W (10.00mm x 10.00mm)
Height - Seated (Max) 0.201" (5.10mm)
Base Product Number SRU1048A
Other Names SRU1048A-330Y,SRU1048A-330YCT,SRU1048A-330YTR,SRU1048A-330YDKR
Standard Package 600
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.50.4000
Win Source Part Number 1273127-SRU1048A-330Y
Ultra Librarian 3D Model Ultra Librarian SRU1048A-330Y CAD Model

Description

The SRU1048A-330Y is a shielded drum core, wirewound inductor from Bourns Inc.

  • Inductance: 33 µH
  • Tolerance: ±30%
  • Core Material: Ferrite
  • Q @ Freq: 24 @ 2.52MHz
  • Frequency Self-Resonant: 10MHz
  • DC Resistance: 84mOhm Max
  • Current Rating: 2.1A
  • Temperature Range: -40°C ~ 125°C
  • Dimension: 0.394" L x 0.394" W (10.00mm x 10.00mm)
  • Package: Tape & reel
  • Package/Case: Nonstandard
  • Rating: AEC-Q200 rating
