SRU1038A-2R2Y Real Image
Same model may have multiple batches, images only for reference.

SRU1038A-2R2Y

Part No SRU1038A-2R2Y
Manufacturer Bourns Inc.
Catalog Fixed Inductors
Datasheet
SRU1038A-2R2Y Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes>Fixed Inductors
Mfr Bourns Inc.
Series SRU1038A
Package Tape & Reel
Type Drum Core, Wirewound
Material - Core Ferrite
Inductance 2.2 µH
Tolerance ±30%
Current Rating (Amps) 6.8 A
Current - Saturation (Isat) 6.5A
Shielding Shielded
DC Resistance (DCR) 10.5mOhm Max
Q @ Freq 12 @ 7.96MHz
Frequency - Self Resonant 55MHz
Ratings AEC-Q200
Temperature Range - Operating -40°C ~ 125°C
Inductance Frequency - Test 100 kHz
Mounting SMD (SMT)
Package / Case Nonstandard
Dimension 0.394" L x 0.394" W (10.00mm x 10.00mm)
Height - Seated (Max) 0.161" (4.10mm)
Base Product Number SRU1038A
Other Names SRU1038A-2R2YDKR,SRU1038A-2R2YCT,SRU1038A-2R2YTR,SRU1038A-2R2Y
Standard Package 800
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.50.4000
Win Source Part Number 1273148-SRU1038A-2R2Y
Ultra Librarian 3D Model Ultra Librarian SRU1038A-2R2Y CAD Model

Description

The SRU1038A-2R2Y is an inductor, coil, and choke electronic component manufactured by Bourns Inc.

  • Series: SRU1038A
  • Type: Drum Core, Wirewound
  • Package: Tape and Reel
  • Shielding: Shielded
  • Inductance: 2.2 µH
  • Height: 0.161" (4.10mm)
  • Standard Package: 800 units
  • Mounting: SMD (SMT)
  • Tolerance: ±30%
  • AEC-Q200: Rated
  • Core Material: Ferrite
  • Q @ Freq: 12 @ 7.96MHz
  • Frequency of Self-Resonant: 55MHz
  • Package/Case: Nonstandard
  • DC Resistance (DCR): 10.5mOhm Max
  • Temperature Range: -40°C ~ 125°C
  • Dimension: 0.394" L x 0.394" W (10.00mm x 10.00mm)
  • Current Rating (amps): 6.8 A
  • Inductance Frequency-Test: 100 kHz
  • REACH: Unaffected
  • HTSUS: 8504.50.4000
