SRP5020C-8R2M Real Image
Same model may have multiple batches, images only for reference.

SRP5020C-8R2M

Part No SRP5020C-8R2M
Manufacturer Bourns Inc.
Catalog Fixed Inductors
Datasheet
SRP5020C-8R2M Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes>Fixed Inductors
Mfr Bourns Inc.
Series SRP5020C
Package Tape & Reel
Material - Core Metal
Inductance 8.2 µH
Tolerance ±20%
Current Rating (Amps) 2.6 A
Current - Saturation (Isat) 4A
Shielding Shielded
DC Resistance (DCR) 171mOhm Max
Q @ Freq 20 @ 100kHz
Frequency - Self Resonant 15MHz
Temperature Range - Operating -40°C ~ 125°C
Inductance Frequency - Test 100 kHz
Mounting SMD (SMT)
Package / Case Nonstandard
Dimension 0.224" L x 0.205" W (5.70mm x 5.20mm)
Height - Seated (Max) 0.079" (2.00mm)
Other Names 118-SRP5020C-8R2MCT,118-SRP5020C-8R2MDKR,118-SRP5020C-8R2MTR
Standard Package 3,000
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.50.8000
Win Source Part Number 1273890-SRP5020C-8R2M
Ultra Librarian 3D Model Ultra Librarian SRP5020C-8R2M CAD Model

Description

The SRP5020C-8R2M is a shielded fixed inductor manufactured by Bourns Inc.

  • Series: SRP5020C
  • Inductance: 8.2 μH
  • DC Resistance: 171mOhm max
  • Q Rating: 20 @ 100kHz
  • Frequency Self-Resonant: 15MHz
  • Current Rating: 2.6A
  • Package Type: Tape and Reel
  • Mounting Technology: SMD (SMT)
  • Tolerance: ±20%
  • Core Material: Metal
  • Temperature Range: -40°C to 125°C
