Same model may have multiple batches, images only for reference.
SRP1245C-100M Real Image
Same model may have multiple batches, images only for reference.

SRP1245C-100M

Part No SRP1245C-100M
Manufacturer Bourns Inc.
Catalog Fixed Inductors
Datasheet
SRP1245C-100M Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes>Fixed Inductors
Mfr Bourns Inc.
Series SRP1245C
Package Tape & Reel
Material - Core Metal
Inductance 10 µH
Tolerance ±20%
Current Rating (Amps) 11 A
Current - Saturation (Isat) 17A
Shielding Shielded
DC Resistance (DCR) 25.5mOhm Max
Q @ Freq 20 @ 100kHz
Frequency - Self Resonant 10MHz
Temperature Range - Operating -40°C ~ 125°C
Inductance Frequency - Test 100 kHz
Mounting SMD (SMT)
Package / Case Nonstandard
Dimension 0.531" L x 0.496" W (13.50mm x 12.60mm)
Height - Seated (Max) 0.197" (5.00mm)
Other Names 118-SRP1245C-100MCT,118-SRP1245C-100MTR,118-SRP1245C-100MDKR
Standard Package 500
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.50.8000
Win Source Part Number 1274068-SRP1245C-100M
Ultra Librarian 3D Model Ultra Librarian SRP1245C-100M CAD Model

Description

The SRP1245C series from Bourns Inc. is a range of fixed inductors that come in a tape and reel package.

  • Shielding: Shielded
  • Inductance: 10 µH
  • Tolerance: ±20%
  • Core Material: Metal
  • Q @ Freq: 20 @ 100kHz
  • Frequency Self-Resonant: 10MHz
  • DC Resistance (DCR): 25.5mOhm Max
  • Other Names: 118-SRP1245C-100MCT, 118-SRP1245C-100MTR, and 118-SRP1245C-100MDKR
  • Operating Temperature: -40°C ~ 125°C
  • Current Rating: 11 A
  • Series: SRP1245C
