Same model may have multiple batches, images only for reference.

SRP0620-100K

Name: SRP0620-100K
Brand: Bourns Inc.
SKU: 1274164
Availability: InStock
Rating: 4.84 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	SRP0620-100K
Manufacturer	Bourns Inc.
Catalog	Fixed Inductors
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Inductors, Coils, Chokes>Fixed Inductors
Mfr	Bourns Inc.
Series	SRP0620
Package	Tape & Reel
Material - Core	Metal
Inductance	10 µH
Tolerance	±10%
Current Rating (Amps)	3.6 A
Current - Saturation (Isat)	5A
Shielding	Shielded
DC Resistance (DCR)	96mOhm Max
Q @ Freq	38 @ 2.52MHz
Frequency - Self Resonant	10MHz
Temperature Range - Operating	-40°C ~ 125°C
Inductance Frequency - Test	100 kHz
Mounting	SMD (SMT)
Package / Case	Nonstandard
Dimension	0.280" L x 0.264" W (7.10mm x 6.70mm)
Height - Seated (Max)	0.079" (2.00mm)
Other Names	118-SRP0620-100KTR,118-SRP0620-100KDKR,118-SRP0620-100KCT
Standard Package	1,500
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8504.50.8000
Win Source Part Number	1274164-SRP0620-100K
Ultra Librarian 3D Model	Ultra Librarian SRP0620-100K CAD Model

Alternative Products

Description

The Bourns Inc. SRP0620 series fixed inductor is a reliable and efficient component for use in various applications.

Inductance: 10 µH
Tolerance: ±10%
Package: Tape & Reel
Standard Package: 1,500
Operating Temperature Range: From -40°C to 125°C
Dimension: 0.280" L x 0.264" W (7.10mm x 6.70mm)
Mounting: SMD (SMT)
DC Resistance (DCR): 96mOhm Max
