Same model may have multiple batches, images only for reference.
SRP0420-2R2K Real Image
Same model may have multiple batches, images only for reference.

SRP0420-2R2K

Part No SRP0420-2R2K
Manufacturer Bourns Inc.
Catalog Fixed Inductors
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes>Fixed Inductors
Mfr Bourns Inc.
Series SRP0420
Package Tape & Reel
Material - Core Metal
Inductance 2.2 µH
Tolerance ±10%
Current Rating (Amps) 4.8 A
Current - Saturation (Isat) 6.2A
Shielding Shielded
DC Resistance (DCR) 35.5mOhm Max
Q @ Freq 36 @ 7.96MHz
Frequency - Self Resonant 28MHz
Temperature Range - Operating -40°C ~ 125°C
Inductance Frequency - Test 100 kHz
Mounting SMD (SMT)
Package / Case Nonstandard
Dimension 0.173" L x 0.161" W (4.40mm x 4.10mm)
Height - Seated (Max) 0.079" (2.00mm)
Other Names 118-SRP0420-2R2KTR,118-SRP0420-2R2KDKR,118-SRP0420-2R2KCT
Standard Package 2,500
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.50.8000
Win Source Part Number 1274214-SRP0420-2R2K
Ultra Librarian 3D Model Ultra Librarian SRP0420-2R2K CAD Model

Description

The Bourns SRP0420-2R2K is a shielded fixed inductor.

  • Inductance: 2.2 µH
  • Tolerance: ±10%
  • Q factor: 36 @ 7.96 MHz
  • DC Resistance: 35.5 mOhm max
  • Current Rating: 4.8 A
  • Mounting Type: SMD (SMT)
  • Material: Metal core
  • Frequency: Self-resonant of 28 MHz
  • Operating Temperature Range: from -40°C to 125°C
  • Package Dimensions: 0.173" L x 0.161" W (4.40mm x 4.10mm)
