The SRF1260 series from Bourns Inc. is an array, signal transformer designed for use in various applications.

• Number of Coils: 2
• Height: 0.244" (6.20mm)
• Inductance (Series): 400 µH
• Inductance (Parallel): 100 µH
• Current Rating (Series): 892 mA
• Current Rating (Parallel): 1.78 A
• Current Saturation (Series): 1.1 A
• Current Saturation (Parallel): 2.2 A
• DC Resistance (DCR) (Series): 656mOhm max
• DC Resistance (DCR) (Parallel): 171mOhm max
• Package/Case: Nonstandard
• Packaging: Tape & Reel
• Standard Package: 400
• Temperature Range: -40°C to 125°C
• Applications: Signal transformer
