Same model may have multiple batches, images only for reference.

ASA00B18-L

Name: ASA00B18-L
Brand: Artesyn Embedded Technologies
SKU: 564909
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	ASA00B18-L
Manufacturer	Artesyn Embedded Technologies
Catalog	Power Supplies Board Mount DCDC Converters
Description	DC DC CONVERTER 12V 6W
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Power Supplies - Board Mount - DC DC Converters
Mfr	Artesyn Embedded Technologies
Series	ASA (6W)
Package	Tube
Product Status	Obsolete
Type	Isolated Module
Number of Outputs	1
Voltage - Input (Min)	9V
Voltage - Input (Max)	36V
Voltage - Output 1	12V
Current - Output (Max)	500mA
Power (Watts)	6 W
Voltage - Isolation	1.5 kV
Applications	ITE (Commercial)
Features	SCP
Temperature Range - Operating	-40°C ~ 71°C
Efficiency	81%
Mounting Type	Through Hole
Package / Case	8-DIP Module
Size / Dimension	1.25" L x 0.80" W x 0.40" H (31.8mm x 20.3mm x 10.2mm)
Standard Package	200 pcs
Moisture Sensitivity Level (MSL)	1 (Unlimited)
ECCN	EAR99
HTSUS	8504.40.9580
Win Source Part Number	564909-ASA00B18-L
Ultra Librarian 3D Model	Ultra Librarian ASA00B18-L CAD Model

Alternative Products

Description

The 564909-ASA00B18-L is an obsolete power supply module from Artesyn Embedded Technologies.

Series: ASA
Type: isolated modules for board mount DC-DC converters
Application: power supplies in ITE (Commercial) applications
Power Rating: 6W
Maximum Output Current: 500mA
Voltage: 12V
Input Voltage Range: 9V to 36V
Protection: SCP (Short Circuit Protection)
Packaging: tube
Size Dimensions: 1.25" L x 0.80" W x 0.40" H (31.8mm x 20.3mm x 10.2mm)
Operating Temperature Range: -40°C to 71°C
Efficiency: 81%
