The LTC2364IDE-16#PBF is a high-precision, 16-bit Successive Approximation Register (SAR) Analog-to-Digital Converter (ADC) from Analog Devices Inc., designed to deliver exceptional performance with low power consumption. This ADC is an ideal solution for applications requiring high accuracy data acquisition without compromising on power efficiency, such as portable medical devices, industrial process control systems, and battery-powered instruments.

Key Features

• Resolution: The LTC2364IDE-16#PBF offers a 16-bit resolution, providing fine detail in the digital representation of the analog signal.
• Sampling Rate: It features a maximum sampling rate of 250 kSPS (kilo-samples per second), which allows for the capture of rapidly changing signals.
• Low Power: With a typical power consumption of only 1.7mW at the full sampling rate, it is optimized for power-sensitive applications.
• Input Range: The ADC supports a versatile pseudo-differential unipolar input range, accommodating a variety of signal types.
• No Latency: It provides no latency operation, meaning that data is available immediately after conversion, ensuring timely and reliable data acquisition.
• Interface: The device includes a SPI-compatible serial interface, facilitating easy integration with most microcontrollers and digital systems.
• Small Package: Housed in a compact 12-lead DFN package, the LTC2364IDE-16#PBF saves valuable board space in space-constrained applications.

Applications

• Portable Medical Devices
• Industrial Process Control
• Data Acquisition Systems
• Battery-Powered Instruments
• Automated Test Equipment

The LTC2364IDE-16#PBF from Analog Devices Inc. is a testament to the company's commitment to providing advanced technology that meets the stringent requirements of modern electronic systems. By integrating this ADC into your design, you can expect precise and reliable performance, ensuring that your products stand out in terms of quality and efficiency.
