ADUM4402CRIZ-RL: A Robust Quad-Channel Digital Isolator

The ADUM4402CRIZ-RL is a cutting-edge digital isolator designed and manufactured by Analog Devices Inc., a company renowned for its high-performance semiconductor products. This component is part of the ADuM440x series, which are quad-channel digital isolators with integrated, isolated power. The device employs Analog Devices' patented iCoupler® technology to achieve high-speed, robust data isolation.

Key Features

• Channels: The ADUM4402CRIZ-RL offers four independent isolation channels in a robust 16-lead SOIC package, providing flexibility for various data transfer and isolation needs.
• Data Rate: It supports a wide data rate of up to 10 Mbps, making it suitable for high-speed digital interfacing.
• Isolation: With an isolation rating of 2.5 kVrms for 1 minute, the device ensures safety and reliability in applications requiring electrical isolation.
• Integrated DC-to-DC Converter: The integrated, isolated DC-to-DC converter simplifies power supply design by providing up to 500 mW of output power, eliminating the need for an external isolated power supply.
• High-Temperature Operation: The device is capable of operating over an industrial temperature range of -40°C to +125°C, ensuring performance in harsh environments.
• Regulatory Approvals: It is certified by regulatory bodies, meeting UL, CSA, VDE, and CQC standards, which underscores its safety and reliability for international use.

Applications

The ADUM4402CRIZ-RL is ideally suited for a variety of applications where isolation is critical, such as:

• Industrial automation and process control
• Isolated sensor interfaces
• Medical equipment with stringent safety requirements
• Isolated RS-232/RS-422/RS-485 interfaces
• Power supply control and monitoring

Reliability and Quality

Analog Devices Inc. ensures that the ADUM4402CRIZ-RL meets the highest quality and performance standards. The device's robust design is geared towards providing reliable data isolation, even in the most demanding conditions. With its advanced features and proven technology, the ADUM4402CRIZ-RL is an excellent choice for designers looking to integrate reliable isolation in their systems.
