ADV7341BSTZ

Part No ADV7341BSTZ
Manufacturer Analog Devices Inc.
Catalog Interface - Encoders, Decoders, Converters
Description Multiformat Video Encoder, Six 12-Bit Noise Shaped Video® DACS | IC ENCODER VIDEO HDTV 64LQFP
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Analog Devices Inc.
Packaging Tray
Type Video Encoder
Applications DVD, Blu-Ray
Supply Voltage , Analog 3.3V
Supply Voltage , Digital 1.8V
Mounting Style SMD
Manufacturer Package 64-LQFP
Supplier Device Package 64-LQFP
Family Part Number ADV7341
Manufacturer Pack Quantity 1
MSL Level 3 (168 Hours)
Win Source Part Number 1142697-ADV7341BSTZ
Manufacturer Homepage www.analog.com
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian ADV7341BSTZ CAD Model

Description

Product Overview: ADV7341BSTZ

The ADV7341BSTZ is a high-performance, integrated video encoder from Analog Devices Inc., designed to meet the demanding requirements of advanced video applications. This encoder IC is capable of converting digital video signals into high-quality analog outputs with support for a wide range of video formats and standards.

Key Features

  • Multiple Video Formats: The ADV7341BSTZ supports a variety of video input formats including 8-, 10-, and 12-bit YCrCb 4:2:2, as well as 8-bit RGB 4:4:4.
  • High-Quality Outputs: It delivers high-quality composite (CVBS), S-Video (Y/C), and component (YPrPb/RGB) outputs, making it versatile for various applications.
  • Integrated Filters: On-chip filters help to maintain signal integrity and provide sharp, clear images.
  • Programmable Features: The device features programmable luma and chroma filters, allowing customization for specific application requirements.
  • Advanced Power Management: The ADV7341BSTZ includes power-saving features, with low power consumption modes to extend the life of battery-powered devices.
  • Robust Interface: It offers an I²C interface for straightforward communication and control, simplifying system integration and design.

Applications

The ADV7341BSTZ is ideal for a range of applications that require high-quality video encoding, such as:

  • Professional video editing and broadcasting equipment
  • Video surveillance systems
  • Medical imaging devices
  • Automotive infotainment and navigation systems
  • Portable media players

Technical Specifications

Encased in a compact 64-lead LQFP (Low-profile Quad Flat Package), the ADV7341BSTZ operates over an extended temperature range, making it suitable for industrial environments. The device is also compliant with RoHS standards, ensuring adherence to current environmental regulations.

Quality and Reliability

Analog Devices Inc. is known for its commitment to quality, and the ADV7341BSTZ is no exception. It is manufactured to meet high standards of performance and reliability, ensuring that it meets the needs of the most demanding video encoding tasks.

For detailed technical specifications, application notes, and support documentation, customers are encouraged to visit the official Analog Devices website or contact their local sales representative.
