ADUM1442ARQZ

Part No ADUM1442ARQZ
Manufacturer Analog Devices Inc.
Catalog Digital Isolators
Description Micropower Quad-Channel Digital Isolators
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Analog Devices Inc.
Series iCoupler
Packaging Tube
Technology Magnetic Coupling
Isolated Power No
Number of Channels 4
Inputs - Side 1/Side 2 2/2
Channel Type Unidirectional
Voltage - Isolation 2500Vrms
Common Mode Transient Immunity (Minimum) 25kV/μs
Data Rate 2Mbps
Propagation Delay tpLH / tpHL (Maximum) 180ns, 180ns
Pulse Width Distortion (Maximum) 8ns
Rise / Fall Time (Typ) 2ns, 2ns
Operating Supply Voltage 2.25 V ~ 3.6 V
Operating Temperature Range -40°C ~ 125°C
Package 16-SSOP (0.154", 3.90mm Width)
Manufacturer Package 16-QSOP
Win Source Part Number 1142499-ADUM1442ARQZ
Manufacturer Homepage www.analog.com
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian ADUM1442ARQZ CAD Model

Description

ADUM1442ARQZ Digital Isolator by Analog Devices Inc.

The ADUM1442ARQZ is a quad-channel digital isolator designed and manufactured by Analog Devices Inc., a leader in high-performance semiconductors. This component is engineered to provide robust electromagnetic compatibility (EMC) and high-speed signal isolation, particularly for applications requiring the isolation of digital signals between domains with different ground potentials.

Key Features:

  • Channels: The device features four independent isolation channels in a quad-channel configuration, which enhances design flexibility and allows for multiple data streams to be isolated simultaneously.
  • Isolation Technology: Utilizing Analog Devices' patented iCoupler® technology, the ADUM1442ARQZ offers reliable galvanic isolation of up to 2.5kVrms for 60 seconds, minimizing the risk of data corruption and damage due to high voltages.
  • Data Rate: With support for data rates up to 1 Mbps, this isolator is suitable for a variety of digital communication protocols, ensuring swift and accurate data transfer.
  • Power Supply: It operates with a wide power supply range from 2.7 V to 5.5 V, making it versatile for different logic levels and compatible with various system voltages.
  • Package: The ADUM1442ARQZ comes in a compact 16-lead QSOP package, designed to save board space and reduce overall design footprint.
  • Temperature Range: This device is operational over the industrial temperature range of -40°C to +125°C, ensuring reliable performance in harsh environments.
  • Safety and Certifications: It is certified by recognized international safety standards, including UL, CSA, IEC, and VDE, providing assurance of its safety and reliability in electrical isolation applications.

Applications:

The ADUM1442ARQZ is ideal for various applications across multiple industries. It is commonly used in:

  • Industrial automation and control systems
  • Isolated sensor interfaces and data acquisition systems
  • Medical equipment requiring electrical safety and isolation
  • Power supply control and monitoring
  • Automotive systems that demand robust isolation

With its combination of high isolation capability, data integrity, and compact footprint, the ADUM1442ARQZ from Analog Devices Inc. is an excellent choice for designers looking to enhance the safety and performance of their electronic systems.
