The ADP5071ACPZ from Analog Devices Inc. is a high-performance, integrated boost and inverting DC-DC converter designed to provide efficient power solutions for a wide range of applications. This versatile component is capable of generating two independent output voltages from a single 2.85 V to 15 V input, making it an ideal choice for powering dual supply systems such as analog-to-digital converters, digital-to-analog converters, and various mixed-signal devices.

Key Features

• Input Voltage Range: The device can operate from an input voltage range of 2.85 V to 15 V, accommodating a variety of power sources.
• Dual Output: It provides two outputs; a positive boost output and a negative inverting output, which are highly configurable to meet specific design requirements.
• Adjustable Output Voltage: The positive output can be adjusted up to 35 V, and the negative output can be adjusted down to -35 V.
• High Efficiency: With its integrated power switches and minimal external components, the ADP5071ACPZ achieves high power conversion efficiency, reducing power loss and heat generation.
• Compact Package: Housed in a compact 16-lead LFCSP package, it is suitable for space-constrained applications.
• Protection Features: The device includes under-voltage lockout, overcurrent protection, thermal shutdown, and soft start capabilities, ensuring reliable operation under various conditions.

Applications

The ADP5071ACPZ is designed for use in a broad array of applications, including but not limited to:

• Portable and battery-powered equipment
• Industrial and instrumentation systems
• Medical devices
• Optical modules
• Communication infrastructure

With its robust feature set and flexible design options, the ADP5071ACPZ from Analog Devices Inc. is a powerful solution for designers looking to enhance the efficiency and performance of their power management systems.
