Analog Devices Inc. ADM6315-29D2ARTZR7 Voltage Supervisor

The ADM6315-29D2ARTZR7 is a high-precision voltage supervisor designed and manufactured by Analog Devices Inc., a leader in the semiconductor industry. This component is engineered to monitor voltage levels within electronic systems, ensuring that the system operates within safe parameters. It is particularly suitable for applications that require a reliable reset signal for microprocessors (µP) or microcontrollers (µC), thus safeguarding the system from unpredictable behavior during power-up, power-down, or voltage dips.

With a fixed threshold voltage of 2.93V, the ADM6315-29D2ARTZR7 provides a robust solution for systems operating at 3V to 3.3V. It offers a precise monitoring capability with a tight accuracy level, which is critical for sensitive electronic applications. The device features an active-low, push-pull reset output, which ensures a quick and decisive response when the monitored voltage falls below the threshold level.

This voltage supervisor comes in a compact SOT-143 package, making it an excellent choice for space-constrained applications. Its small footprint allows for integration into various designs without significantly impacting the overall board layout. The ADM6315-29D2ARTZR7 also boasts a low power consumption, which is beneficial for portable and battery-powered devices where energy efficiency is paramount.

Key features of the ADM6315-29D2ARTZR7 include:

• Fixed threshold voltage: 2.93V
• High accuracy voltage monitoring
• Active-low, push-pull reset output
• Low power consumption
• Compact SOT-143 package
• Operating temperature range: -40°C to +125°C

Applications for this voltage supervisor are diverse, ranging from portable electronics, data storage systems, and medical devices to automotive control systems and industrial equipment. By providing a reliable reset signal and protecting against voltage anomalies, the ADM6315-29D2ARTZR7 plays a critical role in enhancing the stability and reliability of electronic systems.

Analog Devices Inc.'s commitment to quality ensures that the ADM6315-29D2ARTZR7 meets stringent industry standards, delivering performance and reliability that engineers and designers can trust for their critical applications.
