ADM2682EBRIZ-RL7 - Isolated RS-485 Transceiver with Integrated Transformer Driver from Analog Devices Inc.

The ADM2682EBRIZ-RL7 is a fully integrated, signal and power isolated data transceiver with ±15 kV ESD protection, suitable for high-speed communication on RS-485 networks. Manufactured by Analog Devices Inc., a leader in high-performance semiconductors, this device ensures robust communication in harsh industrial environments.

Key Features:

• Integrated Isolation: The device features Analog Devices Inc.'s iCoupler® technology, providing 2.5 kVrms signal and power isolation, enhancing system reliability and simplifying PCB design.
• High Data Rates: Capable of supporting data rates up to 16 Mbps, the ADM2682EBRIZ-RL7 is designed for high-speed data transmission, making it ideal for modern industrial applications.
• Integrated DC-to-DC Converter: An integrated isoPower® DC-to-DC converter eliminates the need for an external power supply on the isolated side, reducing design complexity and board space.
• ESD Protection: ±15 kV ESD protection on the RS-485 input/output pins provides robust protection against electrostatic discharges, ensuring system stability and longevity.
• Thermal Shutdown Protection: The device includes a thermal shutdown feature to prevent damage from overheating, ensuring safe operation under varying conditions.

Applications:

• Industrial Field Buses
• Building Automation
• Process Control Systems
• Networked Communication Systems

The ADM2682EBRIZ-RL7 is housed in a compact, surface-mount 16-lead wide-body SOIC package, making it suitable for space-constrained applications. Its integrated approach simplifies design and accelerates time-to-market for engineers working on advanced industrial communication systems. With its robust feature set and reliable performance, the ADM2682EBRIZ-RL7 from Analog Devices Inc. is an excellent choice for designers looking to implement isolated RS-485 communication interfaces with minimal external components.

For detailed specifications, application notes, and support resources, visit the Analog Devices Inc. website or contact their customer support for assistance in integrating the ADM2682EBRIZ-RL7 into your next project.
