ADG715BRUZ - High-Performance CMOS Switch from Analog Devices Inc.

The ADG715BRUZ is a state-of-the-art CMOS analog multiplexer from Analog Devices Inc., designed to provide high-speed, low-power operation for a wide range of applications. This device features eight single-pole/single-throw (SPST) switches, offering exceptional performance in signal routing and data acquisition systems.

Constructed with Analog Devices' proprietary iCMOS® (industrial CMOS) process technology, the ADG715BRUZ delivers robustness, reduced power consumption, and increased speed. The iCMOS technology enables the integration of CMOS and bipolar transistors on a single chip, allowing for a design that combines the advantages of both transistor types.

Key Features:

• Multiple Switch Configurations: The ADG715BRUZ can be configured as an 8-to-1 multiplexer, dual 4-to-1 multiplexer, or as an array of eight individual switches, providing flexibility for various circuit designs.
• Low On Resistance: With a typical on resistance of just 4 ohms, this multiplexer ensures minimal signal distortion and attenuation, making it ideal for precision applications.
• Single Supply Operation: The device operates from a single 1.8V to 5.5V power supply, accommodating a wide range of applications from battery-powered devices to industrial equipment.
• Low Power Consumption: The ADG715BRUZ features a low power consumption, with a typical quiescent current of less than 1 µA, making it suitable for power-sensitive applications.
• High-Speed Switching: Fast transition times of approximately 20 ns coupled with a bandwidth of over 200 MHz ensure that the device can handle high-speed signals without significant delay.
• TTL/CMOS Compatible: Logic inputs are TTL and CMOS compatible, allowing for easy integration with digital systems.

Applications:

The ADG715BRUZ is versatile and can be used in various applications, including:

• Data acquisition systems
• Communication systems
• Audio and video signal routing
• Automatic test equipment
• Relay replacement

With its compact TSSOP (Thin Shrink Small Outline Package) form factor, the ADG715BRUZ is suitable for space-constrained designs, offering a high-density solution for switch and multiplexer needs. Whether for industrial, consumer, or communication applications, the ADG715BRUZ from Analog Devices Inc. represents a reliable and efficient choice for designers looking for a high-quality analog switching solution.
