ADG706BRUZ - A High-Performance CMOS Analog Multiplexer

The ADG706BRUZ is a monolithic CMOS device comprising a 16-channel multiplexer from Analog Devices Inc., a leader in high-performance semiconductors for signal processing applications. This analog multiplexer is designed for precision, high-speed signal routing and is suitable for a wide array of applications including data acquisition systems, process controls, and communication systems.

Key Features:

• Channel Configuration: The ADG706BRUZ offers a 16:1 single-ended channel configuration, providing flexibility for various signal routing requirements.
• Low On Resistance: The device features a low on resistance (Ron) of typically 4 ohms, ensuring minimal signal attenuation and distortion when routing signals through the multiplexer.
• Single/Dual Supply Operation: It operates from a single 1.8 V to 5.5 V supply or a dual ±2.5 V supply, making it versatile for different system power requirements.
• Low Power Consumption: With a low power consumption design, the ADG706BRUZ is ideal for power-sensitive applications.
• High Throughput Rate: The fast switching speed allows for high throughput rates, making it suitable for rapidly changing signal environments.
• Break-Before-Make Switching: This feature ensures that no two channels are connected simultaneously, preventing signal cross-talk and preserving signal integrity.
• ESD Protection: The device includes enhanced electrostatic discharge (ESD) protection, which increases its robustness and longevity in harsh electrical environments.

Applications:

• Data acquisition systems
• Communication systems
• Audio and video signal routing
• Relay replacement
• Battery-powered systems
• Sample hold systems

The ADG706BRUZ is available in a TSSOP package, which ensures a compact footprint on the PCB and is fully specified over the extended industrial temperature range of -40°C to +85°C. Its high reliability and performance characteristics make it an excellent choice for designers looking for a multiplexer that can handle both precision analog signals and digital signals with equal ease.

Whether you're designing a sophisticated industrial control system or a high-precision data acquisition module, the ADG706BRUZ from Analog Devices Inc. provides the functionality and performance you need to achieve accurate and reliable signal routing in your electronic designs.
