ADG602BRTZ-REEL7

Part No ADG602BRTZ-REEL7
Manufacturer Analog Devices Inc.
Catalog Interface - Analog Switches, Multiplexers, Demultiplexers
Description Low on resistance, 2.5 OHM maximum
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Manufacturer Analog Devices Inc.
Packaging Reel - TR
Switch Circuit SPST - NC
Number of Circuits 1
On-State Resistance (Maximum) 2.5 Ohm
Operating Supply Voltage 2.7 V ~ 5.5 V
Dual Voltage Supply ±2.7 V ~ 5.5 V
Switch Time (Ton, Toff) (Maximum) 120ns, 75ns
-3db Bandwidth 180MHz
Charge Injection 250pC
Channel Capacitance (CS(off), CD(off)) 50pF, 50pF
Current - Leakage (IS(off)) (Maximum) 250pA
Operating Temperature Range -40°C ~ 85°C (TA)
Package SOT-23-6
Manufacturer Package SOT-23-6
Win Source Part Number 1140342-ADG602BRTZ-REEL7
Manufacturer Homepage www.analog.com
Popularity Medium
Supply and Demand Status Balance
Family Name ADG602
Introduction Date November 14, 2001
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2028
Ultra Librarian 3D Model Ultra Librarian ADG602BRTZ-REEL7 CAD Model

Description

Product Overview: ADG602BRTZ-REEL7

The ADG602BRTZ-REEL7 is a high-performance, CMOS analog switch manufactured by Analog Devices Inc., a leader in precision high-performance electronics. This particular model comes in a compact SOT-23 package and is part of a tape and reel, indicated by the 'REEL7' suffix, which is suitable for automated assembly processes, making it ideal for mass production applications.

Key Features

  • Low On-Resistance: The switch features a low on-resistance (< 0.5 ohms typical), which helps in reducing power loss and preserving signal integrity when the switch is closed.
  • Single Supply Operation: It operates on a single supply voltage ranging from +1.8V to +5.5V, making it versatile for various low-voltage applications.
  • Fast Switching: With fast switching times (tON and tOFF), the ADG602BRTZ-REEL7 ensures rapid response in critical applications where timing is crucial.
  • Low Power Consumption: The switch is designed for low power consumption, which is essential for battery-powered devices to extend operational life.
  • High ESD Protection: It offers excellent electrostatic discharge (ESD) protection, ensuring robustness and reliability in harsh environments.
  • Dual Channel: This switch comes with two independent channels, providing flexibility to control two separate signal paths with a single device.

Applications

The ADG602BRTZ-REEL7 is suitable for a wide range of applications, including but not limited to:

  • Audio and video signal routing
  • Communication systems
  • Data acquisition systems
  • Sample and hold circuits
  • Battery-powered systems
  • Portable instruments

Quality and Reliability

Analog Devices Inc. is known for its commitment to quality, and the ADG602BRTZ-REEL7 is no exception. It undergoes rigorous testing and quality assurance processes to ensure high reliability and performance consistent with the company's reputation in the industry.

In summary, the ADG602BRTZ-REEL7 analog switch from Analog Devices Inc. is a versatile, efficient, and reliable component suitable for a variety of electronic applications. Its low on-resistance, single supply operation, and fast switching capabilities make it a preferred choice for designers looking for high-quality switch solutions.
