Analog Devices Inc. ADG453BRUZ: A Robust CMOS Analog Multiplexer

The ADG453BRUZ is a high-performance analog multiplexer from Analog Devices Inc., a leader in the semiconductor industry. This precision device is a part of the robust ADG451/2/3/4 series, designed to provide efficient single-ended or differential operation, which makes it an excellent choice for a variety of data acquisition and signal routing applications.

Constructed with Analog Devices Inc.'s advanced CMOS technology, the ADG453BRUZ offers low power dissipation alongside a wide signal range. This range extends from the negative supply rail to the positive supply rail, ensuring compatibility with a multitude of analog signals. The device operates with a single +5 V to +15 V supply or dual ±5 V to ±15 V supplies, giving designers flexibility in various system architectures.

The ADG453BRUZ features four independently selectable single-pole, single-throw (SPST) switches, providing the user with precise control over signal paths. Its switch on-resistance is typically low, around 35 ohms, which remains nearly constant over the full analog signal range. This characteristic minimizes signal attenuation and preserves the integrity of the transmitted signal, making it ideal for precision applications.

One of the key advantages of the ADG453BRUZ is its enhanced durability. With its latch-up proof construction, the device can withstand up to 200 mA of latch-up current, ensuring reliable performance even in environments where such events may occur. Moreover, the multiplexer exhibits high ESD (Electrostatic Discharge) protection levels, safeguarding the device against unexpected electrical spikes.

For ease of integration, the ADG453BRUZ is offered in a TSSOP (Thin Shrink Small Outline Package) form factor. This compact packaging allows for a minimized PCB (Printed Circuit Board) footprint, which is crucial for space-constrained applications. The device also features fast switching times and low power dissipation, which are essential for power-sensitive designs.

In summary, the ADG453BRUZ from Analog Devices Inc. is a versatile and robust analog multiplexer that delivers reliable performance for a variety of system designs. Its combination of low on-resistance, wide signal range, and high ESD protection makes it a preferred choice for engineers seeking a multiplexer that does not compromise on performance or durability.
