Product Overview: ADG417BRZ by Analog Devices Inc.

The ADG417BRZ is a high-performance, precision monolithic analog switch from Analog Devices Inc., designed to deliver superior switching performance for a multitude of applications. This component is a part of a series renowned for its reliability and efficiency, and it is particularly suitable for use in communication systems, data acquisition systems, and audio signal routing, among other electronic circuits.

Key Features

• Single SPDT Switch: The ADG417BRZ functions as a single-pole double-throw (SPDT) switch, offering a versatile switching solution for various signal paths in a circuit.
• Low On Resistance: With a low on resistance typically around 45 ohms, this switch ensures minimal signal attenuation when closed, maintaining signal integrity and reducing power loss.
• Low Power Consumption: This device operates with very low power consumption, making it an ideal choice for battery-powered and portable devices where power efficiency is critical.
• Wide Dual Supply Range: The switch can operate with a dual supply voltage range of ±4.5 V to ±18 V, or a single supply range of 9 V to 36 V, providing flexibility in various power environments.
• Fast Switching Times: The ADG417BRZ boasts fast switching times (t_ON and t_OFF) typically less than 150 ns, enabling rapid signal switching which is essential in high-speed applications.
• Break-Before-Make Switching: This feature ensures that the switch break contact with one throw before making contact with the other, preventing momentary short circuits during switching.
• ESD Protection: The device includes electrostatic discharge (ESD) protection circuits on all pins, safeguarding it against damage from ESD events.

Applications

• Test Equipment
• Data Acquisition Systems
• Communication Systems
• Audio and Video Switching
• Relay Replacement
• Military and Aerospace Systems

The ADG417BRZ is offered in a compact SOIC package, making it suitable for space-constrained applications. Its robust design and versatile features make it a go-to component for engineers looking to create reliable and high-performing electronic systems. Analog Devices Inc. continues to provide industry-leading solutions with products like the ADG417BRZ, ensuring precision and quality across a wide range of applications.
