The ADG413BRUZ-REEL7 is a high-performance, quad SPST (single pole single throw) switch manufactured by Analog Devices Inc. This precision analog switch is designed to deliver exceptional signal integrity with low on-resistance and fast switching times, making it an ideal choice for a wide range of applications including data acquisition systems, communication systems, and medical equipment.

Key Features

• Low On-Resistance: The ADG413BRUZ-REEL7 boasts a low on-resistance that typically ranges from 35 ohms, ensuring minimal signal distortion and power loss.
• Single Supply Operation: This switch operates from a single supply voltage ranging from +12V to +30V or a dual supply of ±5V to ±15V, providing versatility in different circuit configurations.
• Fast Switching Times: With t_ON of 175 ns and t_OFF of 145 ns, the device can handle high-speed signal switching, essential for critical applications requiring quick response times.
• Low Power Consumption: The ADG413BRUZ-REEL7 is designed for low power consumption, which is critical for battery-powered and energy-sensitive applications.
• Enhanced Durability: The switch is built to withstand continuous operation, thanks to its latch-up proof construction, which enhances its reliability and longevity.
• Wide Operating Temperature Range: It can operate over the extended industrial temperature range of -40°C to +85°C, suitable for harsh environments.

Applications

• Test Equipment
• Data Acquisition Systems
• Communication Systems
• Medical Equipment
• Audio and Video Switching

The ADG413BRUZ-REEL7 comes in a TSSOP package and is delivered in reel packaging for efficient integration into manufacturing processes. Its robust design and flexible operation make it a go-to component for engineers looking to build reliable and high-performing electronic systems.

With Analog Devices Inc.'s reputation for quality and precision, the ADG413BRUZ-REEL7 is a switch that offers both performance and peace of mind, ensuring that your applications function at their best.
