Product Overview: ADG407BPZ by Analog Devices Inc.

The ADG407BPZ is a high-performance analog multiplexer from Analog Devices Inc., a leading global semiconductor company renowned for its precision engineering and innovative design. This particular component is part of the ADG407 series, which are monolithic CMOS devices comprising of eight single channels and four differential channels.

The ADG407BPZ operates on a single 15 V power supply or dual ±5 V to ±8 V power supplies, making it versatile for various applications. Its robust design allows for a signal range that extends to the supply rails, providing users with greater flexibility in signal routing and management. The device features a low power dissipation characteristic, typically consuming only 5 µW of power, which is critical for power-sensitive designs.

With an on resistance of typically 35 ohms, the ADG407BPZ ensures minimal signal attenuation, and the on resistance profile is very flat over the full analog input range, which means the signal integrity is maintained. The multiplexer also boasts a low charge injection of 1 pC, reducing the amount of disturbance introduced to the signal during channel switching.

The device is packaged in a compact 28-lead PDIP (Plastic Dual In-line Package), designated by the suffix 'PZ', which is suitable for through-hole mounting, thereby providing ease of integration into a wide range of electronic systems. The ADG407BPZ can be used in diverse applications including data acquisition systems, test equipment, battery-powered systems, and communication systems.

Ensuring reliable performance, the ADG407BPZ features an extended industrial temperature range of -40°C to +85°C. Its high off isolation of 80 dB at 100 kHz and fast switching times (t_TRANSITION of 250 ns and t_{BREAK-BEFORE-MAKE} of 150 ns) make it an excellent choice for multiplexing and demultiplexing applications where performance cannot be compromised.

In summary, the ADG407BPZ from Analog Devices Inc. is an exceptional choice for designers looking for a high-performance, low-power, and reliable multiplexer solution that is capable of operating across a broad range of temperatures and supply voltages.
