Product Overview: ADG1412YRUZ

The ADG1412YRUZ is a high-performance, quad single-pole single-throw (SPST) switch from Analog Devices Inc., designed to deliver exceptional signal integrity and robustness in a variety of applications. This component is a part of the renowned ADG1412 series, which is well-known for its high switching speeds and low on-resistance.

Constructed with Analog Devices' proprietary iCMOS® (industrial CMOS) process, the ADG1412YRUZ offers an optimal balance of analog and digital functionality combined with low power consumption and a small package footprint. This makes it an ideal choice for precision analog applications that require high density and low power, such as data acquisition systems, communication systems, and audio/visual equipment.

Key Features

• Low On-Resistance: The switch features a typical on-resistance of just 1.5 ohms, which is consistent over the full signal range.
• Single Supply Operation: It operates on a single supply range from 3.3 V to 16 V or a dual supply range from ±3.3 V to ±8 V, offering flexibility in various power environments.
• High Switching Speeds: With fast transition times typically below 150 ns, the ADG1412YRUZ ensures quick response times in critical applications.
• Low Power Consumption: The device has a low power dissipation, with a typical power consumption of less than 0.01 µW, making it suitable for power-sensitive designs.
• Extended Temperature Range: The device operates over an extended industrial temperature range from -40°C to +125°C, ensuring reliability in harsh conditions.
• Robust ESD Protection: It features a high electrostatic discharge (ESD) protection level, which enhances its durability and lifespan.

Applications

• Automated Test Equipment (ATE)
• Data Acquisition Systems
• Battery-Powered Systems
• Communication Systems
• Audio and Video Switching

The ADG1412YRUZ is offered in a compact TSSOP-16 (Thin Shrink Small Outline Package) and is fully specified for operation over the extended industrial temperature range. Its reliability and performance make it a smart choice for designers looking for a high-quality switch that can handle both analog and digital signals with precision and ease.

For more detailed information, datasheets, and support resources, please visit the Analog Devices Inc. website or contact their support team.
