ADG1407BRUZ by Analog Devices Inc.

The ADG1407BRUZ is a high-performance, monolithic analog multiplexer from Analog Devices Inc., a leader in the semiconductor industry. This multiplexer is part of the ADG1407 series and is designed to operate with a single supply voltage ranging from +9V to +40V or dual supplies of ±4.5V to ±20V, making it highly versatile for various applications.

Encased in a compact TSSOP-16 (Thin Shrink Small Outline Package) footprint, the ADG1407BRUZ offers a 16-lead configuration that is ideal for space-constrained designs. This product features a 7:1 single-channel multiplexer, which allows seven different analog inputs to be channeled through a single output, thus simplifying signal routing and reducing the need for additional components.

The ADG1407BRUZ boasts a low on resistance of typically 3.5 ohms, ensuring minimal signal attenuation and distortion when the switch is closed. Moreover, the on resistance is matched between channels to within 0.2 ohms and remains flat over the full analog signal range, providing excellent linearity and low signal error.

One of the key attributes of the ADG1407BRUZ is its high ESD (Electrostatic Discharge) protection level, withstanding up to 2 kV Human Body Model, which ensures robustness and reliability in harsh electrical environments. The device also features break-before-make switching action, which prevents momentary shorting when switching between channels.

With a typical switching time of just 150 ns and a -3 dB bandwidth of 200 MHz, the ADG1407BRUZ is suitable for high-speed applications, including data acquisition systems, process control, and automatic test equipment. Additionally, the device incorporates a digital interface that is compatible with standard CMOS or LVTTL outputs, allowing for easy integration with microprocessors or digital logic.

In summary, the ADG1407BRUZ from Analog Devices Inc. is a reliable and efficient solution for analog signal multiplexing needs. Its robust design, low on resistance, and fast switching capabilities make it an excellent choice for designers looking to optimize their systems for performance and space.
