77317-412-12LF Real Image
Same model may have multiple batches, images only for reference.

77317-412-12LF

Part No 77317-412-12LF
Manufacturer Amphenol
Catalog Circular Connectors - Housings
Description CONN HEADER R/A 12POS 2.54MM / Connector Header Through Hole, Right Angle 12 position 0.100" (2.54mm)
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>Rectangular Connectors - Headers, Male Pins
Mfr Amphenol ICC (FCI)
Series BERGSTIK®
Package Bulk
Connector Type Header, Breakaway
Contact Type Male Pin
Pitch - Mating 0.100" (2.54mm)
Number of Positions 12
Number of Rows 2
Row Spacing - Mating 0.100" (2.54mm)
Number of Positions Loaded All
Style Board to Board
Shrouding Unshrouded
Mounting Type Through Hole, Right Angle
Termination Solder
Fastening Type Push-Pull
Contact Length - Mating 0.268" (6.80mm)
Contact Length - Post 0.120" (3.05mm)
Insulation Height 0.190" (4.83mm)
Contact Shape Square
Contact Finish - Mating Tin
Contact Finish Thickness - Mating 78.7µin (2.00µm)
Contact Finish - Post Tin
Contact Material Phosphor Bronze
Insulation Material Thermoplastic
Temperature Range - Operating -65°C ~ 130°C
Material Flammability Rating UL94 V-0
Insulation Color Black
Current Rating (Amps) 3A per Contact
Contact Finish Thickness - Post 78.7µin (2.00µm)
Base Product Number 77317
MSL Level 1 (Unlimited)
REACH Status REACH Affected
ECCN EAR99
HTSUS 8536.69.4040
Other Names 77317-412-12LF-ND,609-77317-412-12LF,2266-77317-412-12LF
Standard Package 500
Win Source Part Number 1025648-77317-412-12LF
Ultra Librarian 3D Model Ultra Librarian 77317-412-12LF CAD Model

Description

The Amphenol ICC (FCI) BERGSTIK® 1025648-77317-412-12LF is a rectangular connector header with male pins.

  • Positions: 12
  • Shrouding: Unshrouded
  • Connector Type: Header, Breakaway
  • Contact Type: Male Pin
  • Rows: 2
  • Positions Loaded: All
  • Termination: Solder
  • Fastening Type: Push-Pull
  • Color: Black
  • Package: Bulk
  • Contact Material: Phosphor Bronze
  • Contact Finish: Tin
  • Contact Finish Thickness: 78.7µin (2.00µm)
  • Contact Finish-Post: Tin
  • Pitch-Mating: 0.100" (2.54mm)
  • Contact Layout: 8p8c (RJ45, Ethernet)
  • MSL Level: 1 (Unlimited)
  • REACH: Affected
  • HTSUS: 8536.69.4040
