68024-102HLF Real Image
Same model may have multiple batches, images only for reference.

68024-102HLF

Part No 68024-102HLF
Manufacturer Amphenol
Catalog Circular Connectors - Housings
Description CONN HEADER VERT 2POS 2.54MM / Connector Header Through Hole 2 position 0.100" (2.54mm)
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>Rectangular Connectors - Headers, Male Pins
Mfr Amphenol ICC (FCI)
Series BERGSTIK® II
Package Bag
Connector Type Header
Contact Type Male Pin
Pitch - Mating 0.100" (2.54mm)
Number of Positions 2
Number of Rows 1
Number of Positions Loaded All
Style Board to Board
Shrouding Unshrouded
Mounting Type Through Hole
Termination Solder
Fastening Type Push-Pull
Contact Length - Mating 0.318" (8.08mm)
Contact Length - Post 0.150" (3.81mm)
Overall Contact Length 0.568" (14.43mm)
Insulation Height 0.100" (2.54mm)
Contact Shape Square
Contact Finish - Mating Gold or Gold, GXT™
Contact Finish Thickness - Mating 30.0µin (0.76µm)
Contact Material Phosphor Bronze
Material Flammability Rating UL94 V-0
Insulation Color Black
Current Rating (Amps) 5A
Voltage Rating 110V
Base Product Number 68024
MSL Level 1 (Unlimited)
REACH Status REACH Affected
ECCN EAR99
HTSUS 8536.69.4040
Other Names 68024-102HLF-ND,609-5531
Standard Package 1,000
Win Source Part Number 1005814-68024-102HLF
Ultra Librarian 3D Model Ultra Librarian 68024-102HLF CAD Model

Description

The 68024-102HLF is a rectangular connector header male pin designed for use in a wide range of electronic applications.

  • Series: BERGSTIK II
  • Positions: 2
  • Positions Loaded: All
  • Contact Shape: Square
  • Pitch-Mating: 0.100" (2.54mm)
  • Current Rating: 5A
  • Connector Type: Header
  • Contact Type: Male Pin
  • Contact Finish-Mating: Gold or Gold, GXT™
  • Contact Finish Thickness-Mating: 30.0µin (0.76µm)
  • Usage: Common-used part
