54101-S3016A01LF Amphenol FCI
Same model may have multiple batches, images only for reference.

54101-S3016A01LF

Part No 54101-S3016A01LF
Manufacturer Amphenol FCI
Catalog Rectangular Connectors
Description HEADER BERGSTIK STR / Conn Unshrouded Header HDR 16 POS 2.54mm Solder ST Top Entry Thru-Hole Bag
Datasheet
54101-S3016A01LF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Connectors, Interconnects
Manufacturer Amphenol FCI
Series BERGSTIK
Packaging Bulk
Connector Type Header
Contact Type Male Pin
Pitch - Mating 0.100" (2.54mm)
Style Board to Board
Shrouding Unshrouded
Number of Positions 16
Number of Positions Loaded 15
Number of Rows 1
Mounting Style Through Hole
Termination Solder
Fastening Type Push-Pull
Contact Length - Mating 0.318" (8.08mm)
Contact Length - Post 0.120" (3.05mm)
Overall Contact Length 0.538" (13.67mm)
Insulation Height 0.100" (2.54mm)
Contact Shape Square
Contact Finish - Mating Gold or Gold, GXT
Contact Finish Thickness - Mating 15μin (0.38μm)
Contact Finish - Post Tin
Contact Material Phosphor Bronze
Material Flammability Rating UL94 V-0
Insulation Color Black
Contact Finish Thickness - Post 100μin (2.54μm)
Win Source Part Number 793592-54101-S3016A01LF
Popularity Medium
Supply and Demand Status Limited
Family Name 54101
Introduction Date July 26, 2007
ECCN EAR99
Country of Origin China
Halogen Free Not Compliant
Estimated EOL Date 2034
Ultra Librarian 3D Model Ultra Librarian 54101-S3016A01LF CAD Model

Description

The 793592-54101-S3016A01LF from Amphenol FCI is a board to board connector with 16 positions.

  • Mounting: Through Hole
  • Pitch: 0.100 inches (2.54mm)
  • Contact Finish: Gold or Gold, GXT
