AZ5325-01F Amazing
Same model may have multiple batches, images only for reference.

AZ5325-01F

Part No AZ5325-01F
Manufacturer Amazing
Catalog TVS - Diodes
Description TVS DEVICE 1-CHANNEL 5V
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Circuit Protection - Transient Voltage Suppressors (TVS) - TVS Diodes
Mfr Amazing
Package Strip
Product Status Active
Type Zener
Bidirectional Channels 1
Voltage - Reverse Standoff (Typ) 5V (Max)
Voltage - Breakdown (Min) 7V
Power Line Protection No
Applications General
Temperature Range - Operating -40°C ~ 85°C (TC)
Mounting Type Surface Mount
Package / Case 0402 (1006 Metric)
Supplier Device Package DFN1006P2E
Standard Package 10 pcs
REACH Status Vendor Undefined
Win Source Part Number 759280-AZ5325-01F
Ultra Librarian 3D Model Ultra Librarian AZ5325-01F CAD Model

Description

The Amazing 759280-AZ5325-01F is a Zener type transient voltage suppressor (TVS) diode designed for general circuit protection.

  • Type: Zener TVS Diode
  • Voltage Reverse Standoff: 5V (maximum)
  • Voltage Breakdown: 7V (minimum)
  • Channel Count: Bidirectional, 1
  • Package: 0402 (1006 Metric)
  • Operating Temperature: -40°C to 85°C
  • Manufacturer: Amazing
  • Status: Active
