AZ1065-06Q Amazing
Same model may have multiple batches, images only for reference.

AZ1065-06Q

Part No AZ1065-06Q
Manufacturer Amazing
Catalog TVS - Diodes
Description LOW CAP ESD HIGH SPEED 6-CH 5V
Datasheet
AZ1065-06Q Datasheet
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Category Circuit Protection - Transient Voltage Suppressors (TVS) - TVS Diodes
Mfr Amazing
Package Strip
Product Status Active
Type Zener
Unidirectional Channels 6
Voltage - Reverse Standoff (Typ) 5V (Max)
Voltage - Breakdown (Min) 6V
Voltage - Clamping (Max) @ Ipp 13V (Typ)
Power Line Protection No
Applications USB
Temperature Range - Operating -40°C ~ 85°C (TC)
Mounting Type Surface Mount
Package / Case 8-TSSOP, 8-MSOP (0.118", 3.00mm Width)
Supplier Device Package 8-MSOP
Standard Package 10 pcs
REACH Status Vendor Undefined
Win Source Part Number 66436-AZ1065-06Q
Ultra Librarian 3D Model Ultra Librarian AZ1065-06Q CAD Model

Description

The AZ1065-06Q provides outstanding performance with a focus on high accuracy and dependable operation, making it ideal for mission-critical applications.

Features and Benefits:

  • Enhanced precision for exact data handling.
  • Built-in protection against electrical surges.
  • Robust design for high durability.

Applications:

  • Medical electronic devices
  • Advanced computing platforms
  • Power management systems

The AZ1065-06Q is built to serve in environments where precision and reliability are crucial.
