EP3C16F484I7N Real Image
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Altera
Status Active
Number of LABs/CLBs 963
Number of Logic Elements/Cells 15408
Total RAM Bits 516096
Number of I/O 346
Supply Voltage - Operating 1.15 V to 1.25 V
Mounting SMD (SMT)
Temperature Range - Operating -40°C to 100°C (TJ)
Case / Package 484-FBGA (23x23)
Win Source Part Number 084601-EP3C16F484I7N
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Family Name EP3C16
Introduction Date March 01, 2007
ECCN EAR99
Country of Origin Taiwan
Halogen Free Compliant
Estimated EOL Date 2026
Ultra Librarian 3D Model Ultra Librarian EP3C16F484I7N CAD Model

Description

EP3C16F484I7N FPGA

The EP3C16F484I7N is a versatile and energy-efficient FPGA aimed at delivering exceptional processing capabilities for diverse applications. It is ideal for projects requiring agile hardware design and robust processing power.

  • Applications/Projects:
    • Remote sensing and monitoring
    • Control systems for machinery
    • Home automation systems
    • Multimedia applications
  • Features and Benefits:
    • Delivers 15,408 logic elements for sophisticated logic operations
    • Offers superior power efficiency to maintain performance in energy-sensitive environments
    • Available in a compact 484-pin FineLine BGA package
    • Supports lead-free manufacturing processes with full RoHS compliance
  • Additional Details:
    • Features extensive I/O options, maximizing design versatility
    • Equipped with PLLs for efficient and reliable clock management
    • Enhanced compatibility with various external memory interfaces
