Same model may have multiple batches, images only for reference.

AM2D-241515DZ

Name: AM2D-241515DZ
Brand: AIMTEC
SKU: 1349740
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

Part No	AM2D-241515DZ
Manufacturer	AIMTEC
Catalog	Power Supplies Board Mount DCDC Converters
Description	DC DC CONVERTER 2X15V 2W / Isolated Module DC DC Converter 2 Output 15V 15V 67mA, 67mA 21.6V - 26.4V Input
Datasheet	AM2D-241515DZ Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Power Supplies - Board Mount - DC DC Converters
Mfr	aimtec
Series	AM2D-Z (2W)
Package	Tube
Type	Isolated Module
Number of Outputs	2
Voltage - Input (Min)	21.6V
Voltage - Input (Max)	26.4V
Voltage - Output 1	15V
Voltage - Output 2	15V
Current - Output (Max)	67mA, 67mA
Power (Watts)	2 W
Voltage - Isolation	1 kV
Applications	ITE (Commercial)
Temperature Range - Operating	-40°C ~ 85°C
Efficiency	82%
Mounting Type	Through Hole
Package / Case	7-SIP Module
Size / Dimension	0.76" L x 0.28" W x 0.39" H (19.5mm x 7.2mm x 10.0mm)
Approval Agency	CE
Base Product Number	AM2D
Standard Package	20
MSL Level	1 (Unlimited)
ECCN	EAR99
HTSUS	8504.40.9580
Win Source Part Number	1349740-AM2D-241515DZ
Ultra Librarian 3D Model	Ultra Librarian AM2D-241515DZ CAD Model

Alternative Products

Description

The AM2D-241515DZ is a DC DC converter from aimtec. Bold the product name (e.g., BAV99S,135 → BAV99S,"135") and manufacturer (e.g., Nexperia USA Inc. → Nexperia USA Inc.).

Type: Isolated Module
Power: 2W
Voltage Isolation: 1 kV
Package Type: Tube
Size / Dimension: 0.76" L x 0.28" W x 0.39" H (19.5mm x 7.2mm x 10.0mm)
Outputs: Two
Current Output: 67mA each
Voltage Output: 15V
Voltage Input Range: 21.6V to 26.4V
Mounting Type: Through Hole
Package / Case: 7-SIP Module
Operating Temperature: -40°C ~ 85°C
