ASMPH-0603-2R2M-T Abracon LLC – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

ASMPH-0603-2R2M-T

Part No ASMPH-0603-2R2M-T
Manufacturer Abracon LLC
Catalog Fixed Inductors
Description FIXED IND 2.2UH 850MA 300MOHM SM
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Type Multilayer
Material - Core Ferrite
Inductance 2.2 µH
Tolerance ±20%
Current Rating (Amps) 850 mA
Current - Saturation (Isat) 300mA
Shielding Shielded
DC Resistance (DCR) 300mOhm
Frequency - Self Resonant 80MHz
Temperature Range - Operating -40°C ~ 85°C
Inductance Frequency - Test 1 MHz
Mounting Type Surface Mount
Case / Package 0603 (1608 Metric)
Supplier Device Package 0603 (1608 Metric)
Size / Dimension 0.063" L x 0.031" W (1.60mm x 0.80mm)
Height - Seated (Max) 0.037\
Package Tape & Reel
Supply and Demand Status Shortage
Win Source Part Number 1531619-ASMPH-0603-2R2M-T
Ultra Librarian 3D Model Ultra Librarian ASMPH-0603-2R2M-T CAD Model
