929647-01-08-I Real Image
Same model may have multiple batches, images only for reference.

929647-01-08-I

Part No 929647-01-08-I
Manufacturer 3M
Catalog Circular Connectors - Housings
Description CONN HEADER VERT 8POS 2.54MM / Connector Header Through Hole 8 position 0.100" (2.54mm)
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>Rectangular Connectors - Headers, Male Pins
Mfr 3M
Series 929
Package Bulk
Connector Type Header, Breakaway
Contact Type Male Pin
Pitch - Mating 0.100" (2.54mm)
Number of Positions 8
Number of Rows 1
Number of Positions Loaded All
Style Board to Board
Shrouding Unshrouded
Mounting Type Through Hole
Termination Solder
Fastening Type Push-Pull
Contact Length - Mating 0.235" (5.97mm)
Contact Length - Post 0.110" (2.79mm)
Overall Contact Length 0.445" (11.30mm)
Insulation Height 0.100" (2.54mm)
Contact Shape Square
Contact Finish - Mating Gold
Contact Finish Thickness - Mating 10.0µin (0.25µm)
Contact Finish - Post Gold
Contact Material Copper Alloy
Insulation Material Polybutylene Terephthalate (PBT), Polyester, Glass Filled
Temperature Range - Operating -40°C ~ 105°C
Material Flammability Rating UL94 V-0
Insulation Color Black
Current Rating (Amps) 2.5A
Contact Finish Thickness - Post 10.0µin (0.25µm)
Base Product Number 929647
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8536.69.4040
Other Names 3M156515-08,929647-01-08,929647-01-08-ND,929647E-01-08,929647E-01-08-ND
Standard Package 1
Win Source Part Number 1029822-929647-01-08-I
Ultra Librarian 3D Model Ultra Librarian 929647-01-08-I CAD Model

Description

The 3M 1029822-929647-01-08-I is an 8-position, male pin header with breakaway termination.

  • Series: 929
  • Package: Bulk
  • Pieces per Package: 1
  • Contact Material: Copper Alloy
  • Contact Finish: Gold
  • Contact Finish Thickness: 10.0µin (0.25µm)
  • Temperature Range: -40°C to 105°C
  • Alternative Parts: 70545-0176, 3-647629-5, and 827730-6
  • ECCN: EAR99
  • HTSUS: 8536.69.4040
