81026-600203-RB Real Image
Same model may have multiple batches, images only for reference.

81026-600203-RB

Part No 81026-600203-RB
Manufacturer 3M
Catalog Circular Connectors - Housings
Description CONN HEADER VERT 26POS 1.27MM / Connector Header Through Hole 26 position 0.050" (1.27mm)
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>Rectangular Connectors - Headers, Male Pins
Mfr 3M
Series 810
Package Bulk
Connector Type Header
Contact Type Male Pin
Pitch - Mating 0.050" (1.27mm)
Number of Positions 26
Number of Rows 2
Row Spacing - Mating 0.100" (2.54mm)
Number of Positions Loaded All
Style Board to Cable/Wire
Shrouding Shrouded - 4 Wall
Mounting Type Through Hole
Termination Solder
Fastening Type Push-Pull
Contact Length - Mating 0.140" (3.56mm)
Contact Length - Post 0.092" (2.34mm)
Insulation Height 0.405" (10.29mm)
Contact Shape Square
Contact Finish - Mating Gold
Contact Finish Thickness - Mating 30.0µin (0.76µm)
Contact Finish - Post Tin
Contact Material Copper Alloy
Insulation Material Liquid Crystal Polymer (LCP)
Features Board Lock
Temperature Range - Operating -55°C ~ 105°C
Material Flammability Rating UL94 V-0
Insulation Color Black
Current Rating (Amps) 0.75A
Contact Finish Thickness - Post 250.0µin (6.35µm)
Base Product Number 81026
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8536.69.4040
Other Names 5111165858,80000901548,7100139705,81026600203RB,51111658581,-81026-600203-RB,05111165858
Standard Package 100
Win Source Part Number 1023903-81026-600203-RB
Ultra Librarian 3D Model Ultra Librarian 81026-600203-RB CAD Model

Description

The 3M 810 series connector is a header connector type with male pins.

  • Positions: 26
  • Board Lock: yes
  • Series: 810
  • Pitch-Mating: 0.050 inches (1.27mm)
  • Mounting Type: through-hole
  • Package: bulk
  • Contact Finish-Mating: gold
  • Contact Finish Thickness-Mating: 30.0µin (0.76µm)
  • Contact Finish-Post: tin
  • Contact Finish Thickness-Post: 250.0µin (6.35µm)
  • Category: Connectors and Interconnects
  • Current Rating: 0.75A
  • Temperature Range: -55℃ to 105℃
  • HTSUS Code: 8536.69.4040
