XC9572XL-10TQG100C Xilinx Inc. XC9572XL-10TQG100C Real Image1 XC9572XL-10TQG100C Real Image2 XC9572XL-10TQG100C Real Image3 XC9572XL-10TQG100C Real Image4 XC9572XL-10TQG100C Real Image5 XC9572XL-10TQG100C Real Image6
Same model may have multiple batches, images only for reference.
XC9572XL-10TQG100C Xilinx Inc. XC9572XL-10TQG100C Real Image1 XC9572XL-10TQG100C Real Image2 XC9572XL-10TQG100C Real Image3 XC9572XL-10TQG100C Real Image4 XC9572XL-10TQG100C Real Image5 XC9572XL-10TQG100C Real Image6
XC9572XL-10TQG100C Xilinx Inc. XC9572XL-10TQG100C Real Image1 XC9572XL-10TQG100C Real Image2 XC9572XL-10TQG100C Real Image3 XC9572XL-10TQG100C Real Image4 XC9572XL-10TQG100C Real Image5 XC9572XL-10TQG100C Real Image6
Same model may have multiple batches, images only for reference.

XC9572XL-10TQG100C

Part No XC9572XL-10TQG100C
Manufacturer Xilinx Inc.
Catalog Embedded - CPLDs (Complex Programmable Logic Devices)
Description IC CPLD 72MC 10NS 100TQFP
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Xilinx Inc.
Packaging Tray
Status Active
Programmable Type In System Programmable (min 10K program/erase cycles)
Delay Time tpd(1) Max 10.0ns
Voltage Supply - Internal 3 V to 3.6 V
Number of Logic Elements/Blocks 4
Number of Macrocells 72
Number of Gates 1600
Number of I/O 72
Temperature Range - Operating 0°C to 70°C (TA)
Mounting SMD (SMT)
Case / Package 100-TQFP (14x14)
Win Source Part Number 088797-XC9572XL-10TQG100C
Family Name XC9572XL
Introduction Date May 01, 1996
ECCN EAR99
Country of Origin Philippines, Republic of Korea, Taiwan
Halogen Free Compliant
Estimated EOL Date 2023
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian XC9572XL-10TQG100C CAD Model

Description

The XC9572XL-10TQG100C by Xilinx Inc. is a high-performance in-system programmable CPLD (Complex Programmable Logic Device) with 1600 gates, 4 blocks of logic elements, and 72 macrocells.

  • Gates: 1600
  • Logic Elements/Blocks: 4
  • Macrocells: 72
  • Delay Time tpd(1) max: 10.0ns
  • Program/Erase Cycles: 10K (min)
  • Voltage Supply - Internal: 3 V to 3.6 V
  • Mounting: 100-TQFP (14x14) Tray
  • Supply and Demand: Limited
  • Regulations: Halogen-Free
