VS-10BQ040TRPBF Real Image VS-10BQ040TRPBF real image VS-10BQ040TRPBF label picture
Same model may have multiple batches, images only for reference.
VS-10BQ040TRPBF Real Image VS-10BQ040TRPBF real image VS-10BQ040TRPBF label picture
VS-10BQ040TRPBF Real Image VS-10BQ040TRPBF real image VS-10BQ040TRPBF label picture
Same model may have multiple batches, images only for reference.

VS-10BQ040TRPBF

Part No VS-10BQ040TRPBF
Manufacturer Vishay
Catalog Diodes, Rectifiers - Single
Description DIODE SCHOTTKY 40V 1A SMB
Datasheet
VS-10BQ040TRPBF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Vishay
Packaging Reel - TR
Status Obsolete(EOL)
Diode Type Schottky
Voltage - DC Reverse (Vr) (Max) 40V
Current - Average Rectified (Io) 1A
Voltage - Forward (Vf) (Max) @ If 530mV @ 1A
Speed(Frequency) Fast Recovery = 200mA (Io)
Current - Reverse Leakage @ Vr 100μA @ 40V
Mounting SMD (SMT)
Case / Package SMB
Operating Temperature - Junction -55°C to 150°C
Win Source Part Number 122892-VS-10BQ040TRPBF
Family Name VS-10BQ040
Introduction Date June 02, 2010
ECCN EAR99
Halogen Free Unknown
Estimated EOL Date Obsolete
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian VS-10BQ040TRPBF CAD Model

Description

The VS-10BQ040TRPBF is a Schottky diode designed for use in discrete semiconductor products.

  • Package: Reel
  • Mounting Technology: SMD (SMT)
  • Maximum DC Reverse Voltage: 40V
  • Average Rectified Current: 1A
  • Forward Voltage: 530mV @ 1A
  • ECCN: EAR99 compliant
  • Lifecycle Status: Obsolete
