TCMD4000 Real Image TCMD4000 Real Image1 TCMD4000 Real Image2 TCMD4000 Real Image3 TCMD4000 Real Image4
Same model may have multiple batches, images only for reference.
TCMD4000 Real Image TCMD4000 Real Image1 TCMD4000 Real Image2 TCMD4000 Real Image3 TCMD4000 Real Image4
TCMD4000 Real Image TCMD4000 Real Image1 TCMD4000 Real Image2 TCMD4000 Real Image3 TCMD4000 Real Image4
Same model may have multiple batches, images only for reference.

TCMD4000

Part No TCMD4000
Manufacturer Vishay
Catalog Optoisolators - Transistor, Photovoltaic Output
Description OPTOISO 3.75KV 4CH DARLNG 16-SOP
Datasheet
TCMD4000 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Vishay
Packaging Reel - TR
Status Active
Number of Channels 4
Isolation Voltage 3750Vrms
Minimum DC Current Transfer Ratio 600% @ 1mA
Switching Turn-On and Turn-Off Time -, 250μs
Rise and Fall Time 300μs, -
Input Type DC
Output Type Darlington
Maximum Output Voltage 35V
Channel Output Current 80mA
Forward Voltage 1.25V
Continuous forward current- Max 60mA
Vce Saturation (Max) 1V
Temperature Range - Operating -40°C to 100°C
Mounting SMD (SMT)
Case / Package 16-SOP
Win Source Part Number 1106403-TCMD4000
Popularity Medium
Supply and Demand Status Balance
Application Field Used in Industrial, Communications & Networking
Ultra Librarian 3D Model Ultra Librarian TCMD4000 CAD Model

Description

The TCMD4000 is an active 4-channel Darlington output type optocoupler manufactured by Vishay.

  • Isolation Voltage: 3750Vrms
  • Minimum DC Current Transfer Ratio: 600% @ 1mA
  • Temperature Range: -40°C to 100°C
  • Category: Isolators
